Q3 Series Window Screen Integration Casement Window
Q3 Series Window Screen Integration Casement Window
Q3 Series Window Screen Integration Casement Window
Profile Thickness:2.0mm primary aluminum, fluorocarbon powder coating
Standard Glass:5mm+20A+5mm, fluorocarbon grey embossed aluminum
Fan Size:75mm*51mm
Glass Crimping:bevel crimping/optionally closed bevel crimping
Bezel Width:110mm
Thermal Bar:PA66-GF25 thermal bar
Standard Hardware: Eisen hardware, Eisen inner opening and inner inverting
Fan Size:W:350mm~720mm, H:600mm~1550mm Maximum glass can be double 12mm.
Appearance Design:
Narrow window frame design, with a large glass, the field of vision through the light good, suitable for modern simple, light luxury decoration styles
Structural Performance:
a variety of crimping styles to choose from, with good mechanical stability, able to withstand large external forces, to meet the needs of personalization.
Structural stability and waterproof installation and maintenance: no need to glue the internal and external adhesive strips for fixing the glass.
Continuous And Tight Locking:
Handle adopts two-way linkage transmission design with bearing locking point, which ensures tight locking and improves safety.
Performance Parameters:
Wind Pressure:Grade 9, Air Tightness:Grade 6, Water Tightness:Grade 6, Sound Insulation:Grade 4, Heat Insulation:Grade 6.
White, Grey, Skin Color, Wood Grain, Black, Brown
The role of door and window hardware in construction is mainly in improving the physical properties, durability, aesthetics, ease of use, safety, and overall aesthetics of doors and windows.
We offer the following hardware brands in regular colors including black, silver, champagne and bronze.
Chaper Customized Hardware
American CMECH Hardware
Germany HOPPE Hardware
Germany ROTO Hardware
Germany WEHAG Hardware
